Fuji Electric Yukadan 3,5-5,2 kW R32

Se videonVälj tillbehörVar man kan köpa?Luftkonditioneringskonfigurator

Namn produkt:

Fuji Electric Yukadan

Inomhusdel: RGG09-14KVCB

Utomhusdel: ROG09-14KVCBN


Effekt:

Effektområde kyla: 0,9–5,2 kW

Effektområde värme: 0,9–6,3 kW


Beskrivning:

Luft/luft värmepump för lågt väggmontage

SEER A+++ för kyla och SCOP A+ för värme

Konstruerad för nordiskt klimat

Extremt tystgående, endast 22 dB(A)

10°C underhållsvärme


Användning:

Lämpligt för mindre och medelstora enfamiljshus med

modern konstruktion samt Attefallshus, garage och likande



Övrigt:

Fjärrstyrning via WiFi/GSM som tillval

Driftområde ner till -30°C utomhustemperatur


Köldmedium:

R32

  • 10-year warranty
  • Additional ionic and polyphenol filters
  • Wi-Fi communication
  • Consistent heating
  • Human sensor
  • Filter contamination sensor

Wall mounted air conditioner , wall type air conditioner SPLIT, ASYG – LTCA, Modern design

Fuji Electric Yukadan 3,5-5,2 kW R32

Automatic fan speed
Auto-changeover
Up/down swing flaps
Auto restart
Ion deodorization filter
Apple-catechin filter
10°C HEAT operation
Filter sign
Sleep timer
Weekly timer
Wireless LAN control
Low noise mode
Economy operation
Powerful operation
Timer

Automatic fan speed

341-39994

The microprocessor automatically adjusts the air flow intensity to changes in the room temperature.

Auto-changeover

343-82622

The unit automatically switches between cooling and heating modes depending on the temperature and room temperature settings.

Up/down swing flaps

344-28178

They change the air supply direction vertically (auto swing).

Auto restart

339-11513

In the event of a temporary power failure, the air conditioner will automatically restart in the same operating mode as before, once the power supply is restored.

Ion deodorization filter

354-10717

The filter removes unpleasant odours through oxidisation and reduction of ions generated on the surface of the fine ceramic elements.

Apple-catechin filter

357-24851

Fine dust particles, invisible mould spores, and harmful microorganisms are absorbed thanks to static electricity. Bacterial growth is prevented by polyphenol compounds extracted from apples.

10°C HEAT operation

358-80672

Filter sign

364-57839

LED signals the need for filter cleaning.

Sleep timer

371-77879

The microprocessor gradually changes room temperature to ensure comfortable sleep.

Weekly timer

373-31086

On/Off program available for each day of the week.

Wireless LAN control

378-54208

The optional Wi-Fi adapter makes it possible to control the air conditioner using a factory app via a smartphone or tablet.

Low noise mode

379-58030

The low noise mode of the outdoor unit: depending on installation conditions, the user may select the silent operation setting. The operating time can be set using the programmer.

Economy operation

382-75317

Restriction of the maximum current and power consumption.

Powerful operation

384-81345

Increased heating capacity at low temperatures means that the nominal heating capacity is maintained up to outdoor temperatures of -7°C. The new model can operate at outdoor temperatures as low as -20°C.

Timer

449-75818

The programmer allows to set four operating cycles: on, off, on-off, off-on.

Technical specifications

Model wewn. zewn.

EEC

C/G

SEER

SCOP

Wydajność

C/G

Pobór mocy

C/G

Zasilanie

Wymiary

Masa

Ładunek czynnika







kW

kW

V/pH/Hz

mm

kg

kg (CO2eq-T)

ASYG09LTCA

AOYG09LTCA

A+++

A++

8,5

4,6

2,5

3,2



0,5

0,7



230/1/50

282x870x185

540x790x290

9,5

33

1,0 (2,2)

ASYG12LTCA

AOYG12LTCA

A+++

A++

8,5

4,6

3,5

4,0



0,8

0,9



230/1/50

282x870x185

540x790x290

9,5

40

1,2(2,5)



Dane techniczne dotyczą wybranych modeli z oferty Klima-Therm. Producent stale udoskonala swoje wyroby – aby zweryfikować dane proszę skontaktować się z Autoryzowanym Dealerem. C - chłodzenie, G - grzanie, parametry przepływu powietrza podano dla najwyższej prędkości wentylatora. Nominalna wydajność chłodzenia i grzania wyznaczana jest dla następujących parametrów: tryb chłodzenia temp wew: 27 CDB / 19 CWB, temp zew: 35 CDB / 24 CWB oraz tryb grzania: temp wew: 20 CDB / 15 CWB, temp zew: 7 CDB / 6 CWB.

Dokumentacja zgodna z ErP do pobrania tutaj FUJITSU ErP
