model
|
speed
|
V
|
Qch
|
Qg
|
DPch
|
Dpg
|
Nel
|
Lw
|
Lp
|
|
|
|
m3/h
|
kW
|
kW
|
kPa
|
kPa
|
W
|
dB(A)
|
dB(A)
|
|
CCN 13
|
min
|
140
|
0,88
|
1,08
|
2,4
|
1,8
|
16
|
35
|
26
|
|
med.
|
180
|
1,06
|
1,33
|
3,3
|
2,6
|
22
|
41
|
32
|
|
max
|
280
|
1,50
|
1,93
|
6,1
|
4,9
|
49
|
52
|
43
|
|
CCN 23
|
min
|
200
|
1,37
|
1,60
|
2,9
|
2,3
|
24
|
33
|
24
|
|
med.
|
240
|
1,62
|
1,91
|
3,9
|
3,1
|
27
|
36
|
27
|
|
max
|
380
|
2,37
|
2,86
|
7,6
|
6,3
|
44
|
48
|
39
|
|
CCN 33
|
min
|
290
|
1,97
|
2,30
|
6,4
|
5,2
|
27
|
35
|
26
|
|
med.
|
440
|
2,84
|
3,37
|
12,1
|
9,8
|
42
|
46
|
37
|
|
max
|
540
|
3,34
|
4,02
|
16,2
|
13,4
|
59
|
52
|
43
|
|
CCN 14
|
min
|
140
|
0,97
|
1,14
|
4,7
|
3,7
|
16
|
35
|
26
|
|
med.
|
180
|
1,19
|
1,42
|
6,7
|
5,4
|
22
|
41
|
32
|
|
max
|
280
|
1,74
|
2,10
|
12,9
|
10,7
|
49
|
52
|
43
|
|
CCN 24
|
min
|
200
|
1,44
|
1,69
|
4,4
|
3,5
|
24
|
33
|
24
|
|
med.
|
240
|
1,72
|
2,03
|
6,0
|
4,8
|
27
|
36
|
27
|
|
max
|
380
|
2,57
|
3,12
|
12,1
|
10,2
|
44
|
48
|
39
|
|
CCN 34
|
min
|
360
|
2,49
|
2,90
|
6,7
|
5,5
|
33
|
41
|
32
|
|
med.
|
540
|
3,56
|
4,20
|
12,6
|
10,0
|
59
|
52
|
43
|
|
max
|
620
|
4,02
|
4,77
|
15,5
|
12,6
|
72
|
55
|
46
|
|
CCN 13+1
|
min
|
140
|
0,88
|
0,92
|
2,4
|
1,6
|
16
|
35
|
26
|
|
med.
|
180
|
1,06
|
1,08
|
3,3
|
2,1
|
22
|
41
|
32
|
|
max
|
280
|
1,50
|
1,47
|
6,1
|
3,6
|
49
|
52
|
43
|
|
CCN 23+1
|
min
|
200
|
1,37
|
1,49
|
2,9
|
0,9
|
24
|
33
|
24
|
|
med.
|
240
|
1,62
|
1,71
|
3,9
|
1,2
|
27
|
36
|
27
|
|
max
|
380
|
2,37
|
2,35
|
7,6
|
2,0
|
44
|
48
|
39
|
|
CCN 33+1
|
min
|
290
|
1,97
|
2,12
|
6,4
|
2,0
|
27
|
35
|
26
|
|
med.
|
440
|
2,84
|
2,87
|
12,1
|
3,4
|
42
|
46
|
37
|
|
max
|
540
|
3,34
|
3,30
|
16,2
|
4,3
|
59
|
52
|
43
|
MEASUREMENT CONDITIONS /// Cooling: ambient temp. +27/+19oC d.b./w.b., water parameters +7/+12oC E.W.T/L.W.T /// Heating: ambient temp. +20oC, water parameters +45°C E.W.T. +40°C L.W.T.
/// Sound pressure level is 9 dB(A) lower than the sound power level under reverberant field conditions in a 100 m3 room with 0.5 s reverberation time.
V- Airflow rate [m3/h]
Qch- Total cooling capacity [kW], Qg- Heating capacity [kW]
Δpch- Cooling pressure drop [kPa], Δpg- Heating pressure drop [kPa]
Nel- Electric power input [W], Power supply 230/1/50 V/Ph/Hz
Lp- Sound pressure level cooling [dB(A)], Lw- Sound power level cooling [dB(A)]
