model
|
speed
|
V
|
Qch
|
Qg
|
Δpch
|
Δpg
|
Nel
|
Lw
|
Lp
|
|
|
|
m3/h
|
kW
|
kW
|
kPa
|
kPa
|
W
|
dB(A)
|
dB(A)
|
|
CCN-ECM 13
|
min
|
130
|
0,82
|
1,02
|
2,1
|
1,7
|
8
|
35
|
26
|
|
med.
|
205
|
1,18
|
1,50
|
4,0
|
3,3
|
14
|
46
|
37
|
|
max
|
295
|
1,56
|
2,02
|
6,5
|
5,3
|
29
|
55
|
46
|
|
CCN-ECM 23
|
min
|
215
|
1,46
|
1,72
|
3,2
|
2,6
|
8
|
34
|
25
|
|
med.
|
370
|
2,31
|
2,79
|
7,3
|
6,0
|
16
|
46
|
37
|
|
max
|
540
|
3,16
|
3,85
|
12,6
|
10,4
|
37
|
56
|
47
|
|
CCN-ECM 33
|
min
|
275
|
1,87
|
2,19
|
5,8
|
4,7
|
10
|
36
|
27
|
|
med.
|
430
|
2,78
|
3,30
|
11,7
|
9,4
|
19
|
48
|
39
|
|
max
|
620
|
3,75
|
4,54
|
19,8
|
16,6
|
42
|
58
|
49
|
|
CCN-ECM 14
|
min
|
130
|
0,91
|
1,07
|
4,1
|
3,3
|
8
|
35
|
26
|
|
med.
|
205
|
1,34
|
1,60
|
8,1
|
6,6
|
14
|
46
|
37
|
|
max
|
295
|
1,81
|
2,20
|
13,9
|
11,6
|
29
|
55
|
46
|
|
CCN-ECM 24
|
min
|
215
|
1,55
|
1,82
|
5,0
|
4,1
|
8
|
34
|
25
|
|
med.
|
370
|
2,51
|
3,03
|
11,6
|
9,4
|
16
|
46
|
37
|
|
max
|
540
|
3,50
|
4,32
|
20,8
|
17,1
|
37
|
56
|
47
|
|
CCN-ECM 34
|
min
|
275
|
1,95
|
2,25
|
4,3
|
3,5
|
10
|
36
|
27
|
|
med.
|
430
|
2,94
|
3,44
|
8,9
|
7,4
|
19
|
48
|
39
|
|
max
|
620
|
4,02
|
4,78
|
15,5
|
13,0
|
42
|
58
|
49
|
|
CCN-ECM 13+1
|
min
|
130
|
0,82
|
0,87
|
2,1
|
1,4
|
8
|
35
|
26
|
|
med.
|
205
|
1,18
|
1,18
|
4,0
|
2,5
|
14
|
46
|
37
|
|
max
|
295
|
1,56
|
1,52
|
6,5
|
3,8
|
29
|
55
|
46
|
|
CCN-ECM 23+1
|
min
|
215
|
1,46
|
1,58
|
3,2
|
1,0
|
8
|
34
|
25
|
|
med.
|
370
|
2,31
|
2,31
|
7,3
|
2,0
|
16
|
46
|
37
|
|
max
|
540
|
3,16
|
3,01
|
12,6
|
3,1
|
37
|
56
|
47
|
|
CCN-ECM 33+1
|
min
|
275
|
1,87
|
2,04
|
5,8
|
1,8
|
10
|
36
|
27
|
|
med.
|
430
|
2,78
|
2,82
|
11,7
|
3,3
|
19
|
48
|
39
|
|
max
|
620
|
3,75
|
3,64
|
19,8
|
5,1
|
42
|
58
|
49
|
TEST CONDITIONS /// Cooling: ambient temperature +27/+19oC d.b/w.b, water parameters +7/+12oC E.W.T/L.W.T /// Heating: ambient temperature +20oC, water parameters +45 °C E.W.T./ +40 °C L.W.T.
/// The sound pressure level is 9 dB(A) lower than the sound power level under reverberant field conditions of a 100 m3 room with a reverberation time of 0.5 s.
V- Airflow rate [m3/h]
Qch- Total cooling capacity [kW], Qg- Heating capacity [kW]
Δpch- Cooling pressure drop [kPa], Δpg- Heating pressure drop [kPa]
Nel- Electric power input [W], Power supply 230/1/50 V/Ph/Hz
Lp- Sound pressure level cooling [dB(A)], Lw- Sound power level cooling [dB(A)]
