model
|
speed
|
V
|
Qch
|
Qg
|
ΔPch
|
Δpg
|
Nel
|
Lw
|
Lp
|
FC EER
|
FC COP
|
|
|
|
m3/h
|
kW
|
kW
|
kPa
|
kPa
|
W
|
dB(A)
|
dB(A)
|
|
|
|
CRT-ECM 13
|
min
|
105
|
0,55
|
0,80
|
0,8
|
0,7
|
4,0
|
29
|
20
|
B
|
B
|
|
med.
|
165
|
0,76
|
1,10
|
1,4
|
1,1
|
6,0
|
39
|
30
|
|
max
|
240
|
0,99
|
1,48
|
2,2
|
1,8
|
10,0
|
48
|
39
|
|
CRT-ECM 23
|
min
|
150
|
0,85
|
1,17
|
2,1
|
1,7
|
4,5
|
33
|
24
|
B
|
B
|
|
med.
|
215
|
1,11
|
1,52
|
3,4
|
2,7
|
6,5
|
43
|
34
|
|
max
|
305
|
1,41
|
1,96
|
5,2
|
4,2
|
11,5
|
49
|
40
|
|
CRT-ECM 33
|
min
|
220
|
1,37
|
1,79
|
7,4
|
6,2
|
5,0
|
33
|
24
|
A
|
A
|
|
med.
|
325
|
1,88
|
2,45
|
12,9
|
10,4
|
8,5
|
42
|
33
|
|
max
|
450
|
2,38
|
3,12
|
19,7
|
16,0
|
16,0
|
49
|
40
|
|
CRT-ECM 53
|
min
|
295
|
1,83
|
2,39
|
4,8
|
3,9
|
6,0
|
35
|
26
|
A
|
A
|
|
med.
|
460
|
2,62
|
3,45
|
9,1
|
7,4
|
11,5
|
46
|
37
|
|
max
|
675
|
3,49
|
4,63
|
15,0
|
12,1
|
26,0
|
53
|
44
|
|
CRT-ECM 73
|
min
|
400
|
2,48
|
3,14
|
9,6
|
7,7
|
7,0
|
37
|
28
|
A
|
A
|
|
med.
|
630
|
3,57
|
4,57
|
18,2
|
15,0
|
15,0
|
48
|
39
|
|
max
|
900
|
4,67
|
6,06
|
29,1
|
24,0
|
38,0
|
56
|
47
|
|
CRT-ECM 13+1
|
min
|
95
|
0,51
|
0,62
|
0,7
|
0,7
|
4,0
|
29
|
20
|
B
|
C
|
|
med.
|
150
|
0,72
|
0,85
|
1,3
|
1,1
|
6,0
|
39
|
30
|
|
max
|
225
|
0,95
|
1,09
|
2,0
|
1,8
|
10,0
|
48
|
39
|
|
CRT-ECM 23+1
|
min
|
135
|
0,78
|
0,98
|
1,8
|
1,7
|
4,5
|
33
|
24
|
B
|
B
|
|
med.
|
195
|
1,02
|
1,23
|
2,9
|
2,5
|
6,5
|
43
|
34
|
|
max
|
285
|
1,34
|
1,57
|
4,8
|
3,9
|
11,5
|
49
|
40
|
|
CRT-ECM 33+1
|
min
|
200
|
1,25
|
1,54
|
6,1
|
4,9
|
5,0
|
33
|
24
|
A
|
A
|
|
med.
|
295
|
1,71
|
2,00
|
10,6
|
7,8
|
8,5
|
42
|
33
|
|
max
|
415
|
2,22
|
2,51
|
16,8
|
11,6
|
16,0
|
49
|
40
|
|
CRT-ECM 53+1
|
min
|
270
|
1,69
|
2,05
|
4,2
|
1,6
|
6,0
|
35
|
26
|
A
|
A
|
|
med.
|
420
|
2,44
|
2,76
|
8,0
|
2,7
|
11,5
|
46
|
37
|
|
max
|
640
|
3,35
|
3,67
|
14,0
|
4,4
|
26,0
|
53
|
44
|
|
CRT-ECM 73+1
|
min
|
355
|
2,26
|
2,67
|
8,2
|
3,0
|
7,0
|
37
|
28
|
A
|
B
|
|
med.
|
565
|
3,29
|
3,68
|
15,8
|
5,2
|
15,0
|
48
|
39
|
|
max
|
820
|
4,35
|
4,72
|
25,7
|
8,1
|
38,0
|
56
|
47
|
MEASUREMENT CONDITIONS /// Cooling: ambient temp. +27/+19oC d.b./w.b., water parameters +7/+12oC E.W.T/L.W.T /// Heating: ambient temp. +20oC, water parameters +45°C E.W.T. +40°C L.W.T.
/// Sound pressure level is 9 dB(A) lower than the sound power level under reverberant field conditions in a 100 m3 room with 0.5 s reverberation time.
V- Airflow rate [m3/h]
Qch- Total cooling capacity [kW], QchJ- Sensible cooling capacity [kW], Qg- Heating capacity [kW]
Δpch- Cooling pressure drop [kPa], Δpg- Heating pressure drop [kPa]
Nel- Electric power input [W], Power supply 230/1/50 V/Ph/Hz
Lp- Sound pressure level cooling [dB(A)], Lw- Sound power level cooling [dB(A)]
FCEER- Energy efficiency class cooling, FCCOP- Energy efficiency class heating.
